PC MINI ASUS NUC RNUC13ANHI30000 ARENA CANYON I3 T

SIN CABLE DE ALIMENTACION
Processor
Built-in processor:Yes
Processor manufacturer:Intel
Processor family:Intel® Core? i3
Processor generation:Intel Core i3-13xxx
Processor model:i3-1315U
Processor cores:6
Processor threads:8
Performance cores:2
Efficient cores:4
Performance-core boost frequency:4.5 GHz
Efficient-core boost frequency:3.3 GHz
Processor boost frequency:4.5 GHz
Processor cache:10 MB
Processor codename:Raptor Lake
CPU configuration (max):1
Memory
Memory slots type:SO-DIMM
Number of memory slots:2
Number of DIMM slots:2
Maximum internal memory:64 GB
Supported memory clock speeds:3200 MHz
Supported memory types:DDR4-SDRAM
Memory channels:Dual-channel
Memory voltage:1.2 V
ECC:No
Non-ECC:Yes
Audio
Built-in speaker(s):No
Ports & Interfaces
USB 2.0 ports quantity:1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:3
HDMI ports quantity:1
Ethernet LAN (RJ-45) ports:1
HDMI version:2.1
DisplayPorts quantity:1
Combo headphone/mic port:Yes
Thunderbolt ports quantity:2
Serial port via internal header:No
Number of SATA III connectors:1
M.2 card slot (wireless):2230 (E-key) (E)
USB ports quantity:4
M.2 card slot (storage):2280 NVMe (M); 2242 SATA (B)
Thunderbolt 4 ports quantity:2
DC-in jack:Yes
Weight & Dimensions
Width:4.61” (11.70 cm)
Depth:4.41” (11.20 cm)
Height:2.13” (5.40 cm)
Power
Power supply type:External AC adapter
Network
Ethernet LAN:Yes
Wi-Fi:Yes
Top Wi-Fi standard:Wi-Fi 6E (802.11ax)
Wi-Fi standards:Wi-Fi 6E (802.11ax)
WLAN controller model:Intel Wi-Fi 6E AX211
LAN controller:Intel I226-V
Bluetooth:Yes
Bluetooth version:5.3
Storage
Supported storage drive types:SSD
Storage drive sizes supported:M.2, 2.5”
SSD form factor:M.2
Storage drive interface:PCI Express, Serial ATA III
NVMe:Yes
Number of storage drives supported:3
Packaging Content
Power cord included:Yes
Expansion Slots
PCI Express slots version:4.0
Number of M.2 (M) slots:1
Other Features
Additional headers:Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2×2 power connector
Number of SATA connectors:1
HDD size:2.5”
DC input voltage:12 – 20 V
Launch date:Q1’23
Design
Chassis type:UCFF
Product color:Black
Cooling type:Active
Product type:Mini PC barebone
On/off switch:Yes
LED indicators:Yes
ARK ID:233096
Status:Launched
Product family:Intel NUC
Product codename:Arena Canyon
Graphics
On-board graphics card:No
Graphics card family:Intel
On-board graphics card model:Intel® UHD Graphics
Maximum resolution:7680 × 4320 pixels
Number of displays supported:4
Processor Special Features
Intel® High Definition Audio (Intel® HD Audio):Yes
Embedded options available:No
Intel® AES New Instructions (Intel® AES-NI):Yes
Intel Virtualization Technology for Directed I/O (VT-d):Yes
Intel VT-x with Extended Page Tables (EPT):Yes
Intel Flex Memory Access:Yes
Intel Trusted Execution Technology:Yes
Execute Disable Bit:Yes
Intel ME Firmware Version:16.1
Intel® Optane? Memory Ready:No
Intel® Platform Trust Technology (Intel® PTT):Yes
